Frame

Cub-Scout 14″ 6061-T6 Custom-Butted Aluminium

Material

Aluminium

Bike Weight

6.69kg (Inc Pedals)

Fork

Cub-Scout 14″ 6061-T6 Custom-Butted Aluminium, Straight Steerer

Groupset

Single Speed Kids 25x14T

Crank

Samox crank 89mm, 25t, double chain guard

Cassette

Single speed with 25x14t gearing

Front Brake

Tektro JL352-rs short reach lever on clarks mechanical caliper.

Rear Brake

Tektro JL352-rs short reach lever on clarks mechanical caliper.

rotor

F: 160mm R: 140mm

chain

KMC Z1 Wide

Wheelset

F: 100x10mm female axle hub on 14″ 16h rim R: 110x10mm female axle hub on 14″ 20h rim

Outer Tyre

Vee Rubber – 14×2.25″ crown gem

headset

VP Components Sealed Bearing, EX34-28.6/ EX34/30

Handlebar

Nukeproof, 480mm wide, 25mm rise, 19mm dia grip area, 25.4mm clamp

handlebar_grips

19mm diameter closed end grips

Stem

40mm Nukeproof

Saddle

Nukeproof one piece saddle and 27.2mmx260mm post

Range

Youth

14″

A

Reach

258.46

B

Stack

323.73

C

Effective Top Tube Length

360.4

D

Seattube Length

190

E

Effective Seattube Angle

72.5

F

Seattube Angle (Actual)

72.5

I

Headtube Length

100

J

Headtube Angle

67.5

K

Chainstay Length

260

L

Front Centre

421

M

Wheelbase

680.7

N

Bottom Bracket Drop

10

O

Bottom Bracket Height

172

P

Stand Over Height

380.15

R

Trail

42.9

S

Fork Offset

30

T

Axle to Crown

242

U

Maximum Seatpost Insert

165
