FRAME : ACX ALL-ROUND, ICR READY SADDLE : LINC GLYD
SIZES (CT) : XXS, XS, S, M, L, XL, XXL RAIL : CR-MO ø 7mm
FRAME COLOR : METALLIC BLACK
DECAL COLOR : BRONZE SEATPOST : POLYGON EXPERT ALLOY
HEAD TUBE I.D. : 52mm D x L : 27.2x350mm
BRAKE ROUTE : FULLY INTERNAL OFFSET : 4mm
SHIFTER ROUTE : FULLY INTERNAL SEAT CLAMP : INTEGRATED SHAPE W/ BOLT
FRONT DERAILLEUR : BRAZE-ON DOWN-PULL
BB SHELL : T47 BB68 DRIVETRAIN
ISCG MOUNT : – CRANKSET : SHIMANO 105 R7100, 50/34T
BRAKE TYPE : DISC BRAKE FLAT 140mm THICKNESS: 25mm CRANKSET – MAX CHAIN RING : 53/39T
HUB SPACING : 12x142mm CRANKSET – CRANK ARM : 165 (XXS, XS, S) / 170mm (M, L) / 172.5mm (XL, XXL)
FOR THRU AXLE TP1.0 L: 168mm PEDAL : –
BOTTOM BRACKET : TOKEN T47 FOR 24mm SPINDLE, 68mm
HEADSET : INTEGRATED (IS) SEALED BEARING FOR OS HEAD TUBE CHAIN : KMC X12
S.H.I.S. : IS 52/28.6 | IS 52/40 CASSETTE SPROCKET : SHIMANO 105 R7101, 11-34T
FRONT DERAILLEUR : SHIMANO 105 R7100 BRAZE ON
FORK : ACX ALL-ROUND REAR DERAILLEUR : SHIMANO 105 R7100
FEATURES : FULL CARBON SHIFTING LEVER : SHIMANO 105 R7120, 2×12 SPEED
STEERER : TAPER 1-1/8″ TO 1-1/2″
BRAKE TYPE : DISC BRAKE FLAT 140mm/160mm BRAKES : SHIMANO 105 HYDRAULIC DISC
HUB SPACING : 12x100mm W/ THRU AXLE TP1.5 L: 120mm BRAKE LEVER : SHIMANO 105 R7120
BRAKE SET : SHIMANO 105 R7170 FLAT
REAR SHOCK : – ROTOR : SHIMANO RT54 F: 160mm / R: 160mm CENTER LOCK
FEATURES : –
E2E : – TYRES : SCHWALBE ONE ADDIX TLE 700x30C
HARDWARE : – MAXIMUM SIZE : 700x34C
HANDLEBAR : POLYGON EXPERT ALLOY WHEELS : POLYGON RD6 DISC
WIDTH : 380mm (XXS, XS, S) / 400mm (M, L) / 420mm (XL, XXL) FRONT RIM : ALLOY DOUBLE WALL 622-19 24H FOR TYRE 622-28/62, DISC TUBELESS READY
BAR BORE : 31.8mm REAR RIM : ALLOY DOUBLE WALL 622-19 24H FOR TYRE 622-28/62, DISC TUBELESS READY
RISE/DROP : 125mm FRONT HUB : ALLOY THRU AXLE 12x100mm 24H SEALED BEARINGS CL
BEND/REACH : 70mm REAR HUB : ALLOY THRU AXLE 12x142mm 24H SEALED BEARINGS CL
FOR CASSETTE SPROCKET
HANDLE STEM : POLYGON EXPERT ALLOY FRONT SPOKE : STAINLESS SPOKES NDS: 278mm DS: 280mm
EXTENSION : 90mm (XXS) / 100mm (XS, S) / 110mm (M, L) / 120mm (XL, XXL) REAR SPOKE : STAINLESS SPOKES NDS: 280mm DS: 278mm
BAR BORE : 31.8mm
RISE/DROP : 7degree EXTRAS
–
