Geometri
Geometry & Size Allroad
S | M | L | XL | |
---|---|---|---|---|
Height (cm) | 150-163 | 163-175 | 175-188 | 188-195 |
Seat Tube Length (A) | 404 | 448 | 492 | 535 |
Seat Tube Angle (B) | 74.75 | 74.26 | 73.76 | 73.26 |
Effective Seat Tube Angle (C) | 74.75 | 74.26 | 73.76 | 73.26 |
Head Tube Length (D) | 143 | 163 | 193 | 221 |
Head Tube Angle (E) | 70.25 | 71.77 | 72.06 | 72.26 |
Effective Top Tube (F) | 526 | 550 | 581 | 610 |
Bb Height (G) | 265 | 265 | 265 | 265 |
Bb Offset (H) | 79 | 79 | 79 | 79 |
Chainstay Length (I) | 415 | 415 | 415 | 415 |
Wheelbase (J) | 997 | 1003 | 1026 | 1048 |
Frame Reach (K) | 371 | 383 | 400 | 415 |
Frame Stack (L) | 566 | 591 | 621 | 648 |
Standover Height (M) | 701 | 741 | 784 | 819 |
