RAME : ACX ALL-ROUND, ICR READY SADDLE : LINC GLYD
SIZES (CT) : XXS, XS, S, M, L, XL, XXL RAIL : CR-MO ø 7mm
FRAME COLOR : WHITE
DECAL COLOR : BRONZE SEATPOST : POLYGON EXPERT ALLOY
HEAD TUBE I.D. : 52mm D x L : 27.2x350mm
BRAKE ROUTE : FULLY INTERNAL OFFSET : 4mm
SHIFTER ROUTE : FULLY INTERNAL SEAT CLAMP : INTEGRATED SHAPE W/ BOLT
FRONT DERAILLEUR : BRAZE-ON DOWN-PULL
BB SHELL : T47 BB68 DRIVETRAIN
ISCG MOUNT : – CRANKSET : PROWHEEL ARE-C607X-TT, 50/34T
BRAKE TYPE : DISC BRAKE FLAT 140mm THICKNESS: 25mm CRANKSET – MAX CHAIN RING : 53/39T
HUB SPACING : 12x142mm CRANKSET – CRANK ARM : 165 (XXS, XS, S) / 170mm (M, L) / 172.5mm (XL-XXL)
FOR THRU AXLE TP1.0 L: 168mm PEDAL : –
BOTTOM BRACKET : TOKEN T47 FOR 24mm SPINDLE, 68mm
FORK : ACX ALL-ROUND CHAIN : KMC X11
FEATURES : FULL CARBON CASSETTE SPROCKET : SHIMANO TIAGRA RS400, 11-36T
STEERER : TAPER 1-1/8″ TO 1-1/2″ FRONT DERAILLEUR : SHIMANO TIAGRA R4000 BRAZE ON
BRAKE TYPE : DISC BRAKE FLAT 140mm/160mm REAR DERAILLEUR : SHIMANO TIAGRA R4000
HUB SPACING : 12x100mm W/ THRU AXLE TP1.5 L: 120mm SHIFTING LEVER : SHIMANO TIAGRA R4020, 2×11 SPEED
REAR SHOCK : – BRAKES : SHIMANO TIAGRA HYDRAULIC DISC
FEATURES : – BRAKE LEVER : SHIMANO TIAGRA R4020
E2E : – BRAKE SET : SHIMANO TIAGRA RS405 HYDRAULIC DISC
HARDWARE : – ROTOR : SHIMANO RT30 F: 160mm / R: 160mm CENTER LOCK
HANDLEBAR : POLYGON EXPERT ALLOY TYRES : SCHWALBE ONE ADDIX TLE 700x30C
WIDTH : 380mm (XXS, XS, S) / 400mm (M, L) / 420mm (XL, XXL) MAXIMUM SIZE : 700x34C
BAR BORE : 31.8mm
RISE/DROP : 125mm WHEELS : POLYGON RD6 DISC
BEND/REACH : 70mm FRONT RIM : ALLOY DOUBLE WALL 622-19 24H FOR TYRE 622-28/62, DISC TUBELESS READY
REAR RIM : ALLOY DOUBLE WALL 622-19 24H FOR TYRE 622-28/62, DISC TUBELESS READY
HANDLE STEM : POLYGON EXPERT ALLOY FRONT HUB : ALLOY THRU AXLE 12x100mm 24H SEALED BEARINGS CL
EXTENSION : 90mm (XXS) / 100mm (XS, S) / 110mm (M, L) / 120mm (XL, XXL) REAR HUB : ALLOY THRU AXLE 12x142mm 24H SEALED BEARINGS CL
BAR BORE : 31.8mm FOR CASSETTE SPROCKET
RISE/DROP : 7degree FRONT SPOKE : STAINLESS SPOKES NDS: 278mm DS: 280mm
REAR SPOKE : STAINLESS SPOKES NDS: 280mm DS: 278mm
HEADSET : INTEGRATED (IS) SEALED BEARING FOR OS HEAD TUBE
S.H.I.S. : IS 52/28.6 | IS 52/40 EXTRAS
