Frame

Trick 26 6061Alloy Stealth Evo, HHG internal cable routing, internal headset, replaceable hanger, BSA bottom bracket, 12x142mm rear axle

Sizes

One size 350mm

Fork

X-Fusion Velvet RL 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem

MDK XC, 6061 forged alloy, 25.4mm barbore, rise: 0º, length: 45mm

Handlebar

MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips

Onoff Twin, 1lock-on

Seatpost

Onoff Pija dropper internal, diameter 31.6x100mm

Saddle

SDG Fly JR

Front brake

Sram Level, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

Rear brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

Brake lever

Sram Level, tooled reach adjust, lever pivot bushings

Rims

MDK-XP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel

Front hub

DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts

Rear hub

DA210RSRA01 12x142mm, cup & cone ball bearings, IS 6 bolts, HG freehub

Front tire

Kenda Booster 26×2.4 single compound 30TPI, wire bead

Rear tire

Kenda Booster 26×2.4 single compound 30TPI, wire bead

Crankset

Sram SX Eagle, DUB axle, Direct mount chain ring, 155mm

Rings

30T, steel, X-Sync

Bottom bracket

Sram DUB BSA, sealed bearings, 73mm

Pedals

SDG Slater JR

Chain

Sram SX Eagle, 12s, Powerlock

Rear derrailleur

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Shift levers

Sram Trigger SX Eagle, 12s, X-Actuation 1:1

Casette

Sram PG-1230, 11-50T, 12s

Derailleur hanger

UDH

Weight

12,5 kg
