Frame

Play 24 6061 Alloy Stealth evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible

Sizes

One size: 320mm

Fork

X-Fusion Velvet RL 26, 100mm, air spring, tapered steerer tube, 15x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload

Headset

Acros AZX-239 R1 Block Lock 135°, ZS44/28.6 top, ZS56/40 bottom

Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Grips

Onoff Twin, 1lock-on

Seatpost

MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm

Saddle

SDG Fly JR

Front brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

Rear brake

Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

Brake lever

Sram Level, tooled reach adjust, lever pivot bushings

Rims

MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes

Spokes

CN round stainless steel

Front hub

DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts

Rear hub

Mahle-Ebikemotion X-35, HG freehub

Front tire

Kenda Booster 24×2.4 single compound 30TPI, wire bead

Rear tire

Kenda Booster 24×2.4 single compound 30TPI, wire bead

Crankset

Samox DM 28T steel, 127mm

Rings

28T, steel

Bottom bracket

BSA, 73mm

Pedals

SDG Slater JR

Chain

Sram PC1110 11s, Powerlock

Rear derrailleur

Sram NX, 11s, long cage, X-actuation 1:1

Shift levers

Sram trigger NX 11s, X-actuation 1:1

Casette

Sram PG 1030 11-42T, 11s

Derailleur hanger

Mondraker M077

Weight

15,3 kg

Display

Mahle-Ebikemotion

Motor

Mahle-Ebikemotion X-35

Battery

Mahle-Ebikemotion Internal 250Wh
