Spesifikasjoner
Frame
F-Play 26 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatible
Sizes
One size: 350mm
Rear shock
X-Fusion 02PRO R, 165x45mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
Shock settings
A-Tune light compression
Fork
X-Fusion Slant RC 26, 140mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
Headset
Onoff ZS44/ZS56, 1-1/8″, 1.5″ head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º
Stem
Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips
Onoff Beehive, 1lock-on, 135mm
Seatpost
X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 125mm
Saddle
SDG Fly JR
Front brake
Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Rear brake
Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
Brake lever
Shimano MT501, servo wave, alloy lever
Rims
MDK-HP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Front hub
DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts
Rear hub
Mahle-Ebikemotion X-30, HG freehub
Front tire
Maxxis Minion DHF 26×2.5, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead
Rear tire
Maxxis Minion DHR II 26×2.4, Tubeless ready, EXO Protection, 60TPI, folding bead
Crankset
Prowheel DMJ-CR094S-TT, Direct mount chainring, 155mm
Rings
30T, steel
Bottom bracket
Prowheel PW-MBB73 73mm
Pedals
SDG Slater JR
Chain
Shimano Deore M6100, 12s, Quick-link
Rear derrailleur
Shimano Deore M6100, SGS, Shadow+, 12s
Shift levers
Shimano Deore M6100, Rapid Fire Plus, 12s
Casette
Sunrace CSMZ600, 11-51T
Derailleur hanger
Mondraker M077
Weight
17,8 kg
Display
iWoc ONE Head Unit
Motor
Mahle X-30, Drive Unit
Battery
Mahle IX250Wh
