Spesifikasjoner
Engine
Bosch Performance Line CX 25/85Nm
Motor support
bis 25 km/h
Akkumodell
Bosch PowerPack 545
Battery (Wh)
545 Wh
Display
Bosch Kiox 500
Frame material
Aluminium
Fork
Original i:SY rigid fork
Derailleur type – gears
Hub gear | 5 speed
Derailleur Shifter
SHIMANO Nexus Revo Shifter
Crankset
i:SY E-Bike crank
Cassette
28T
Brakes
Hydraulic disc brake
Brake
TEKTRO HD-T532, hydraulic 4-piston disc brake
Rear brake
TEKTRO HD-T532, hydraulic 2-piston disc brake
Brake lever
3-finger brake lever
Brake lever rear
3-finger brake lever
Brake disc
180 mm
Brake disc rear
160 mm
Rim
RYDE Andra 40 Disc, 32 H
Rim rear
RYDE Andra 40 Disc, 32 H
Hub (Frontwheel)
SHIMANO Deore HB-M5100
Rear hub
Shimano Inter-5E, SG-C7000-5D
Spokes
32x Niro 2.0 mm
Tires
SCHWALBE Pick Up, Super Defence
Tire size (inch)
20 x 2,35
Tire size (ETRTO)
60-406
Handlebar
i:SY handlebars 30°
Handles
ERGON GC10 ERGONomic handles
Stem
i:SY stem 70mm
Headset
i:SY headset
Saddle
ZECURE, Hydro Foam, size L
Seatpost
i:SY seatpost, 415 mm, ⌀ 34.9mm
Seatclamp
i:SY 1.0 integrated
Pedals
i:SY Anti-slip Folding Pedal
Front lightning set
FUXON FF-100EB, 100 Lux LED with high beam
Rear lightning set
FUXON R-Glow S LED Rear Light
Stand
PLETSCHER Kickstand Comp40 Flex
Mudguards
SKS Bluemels 20 inch, width 65mm
Carrier
i:SY Carrier MonkeyLoad ready
Chain guard/case
HORN Catena
Frame lock
ABUS i:SY set, keyed alike, consisting of battery and frame lock (BLO BOS DT3 + 4750SL NR)
Wheel size
20 Zoll
Frame height
51 cm
maximum weight allowed
180 kg
Weight **
23.9 kg
Charger
Bosch 4A Charger
